Technical data:

• Height: 265mm
• Threads: 1/2 "
• Working pressure: 0.5-12 bar
• Maximum pressure: 16 bar
• Filtration: 40 microns
• Maximum bandwidth: at 7-mic bars 2800 l / min | At 12-hundred bars 1800 l / min
• Minimum airflow: 6 l / min
• Tank capacity: 43 ml
• Working temperature: 0-60 ° C
• Manometer connection thread: 1/4 "

The set consists of:

• Reducture - Setting and maintaining the output pressure
• Filter - air purification from condensate, oil and solid particles

Additional information:

• Reducer type - membrane - Provides permanent pressure on the output and its precise adjustment.
• The reducer has a lock against accidental pressure change - before adjusting, unblock the knob by pulling it up
• The filter does not require additional fasteners, maintains on a nipple or a connector that will be attached to the compressor. It has also been equipped with handles that can be screwed into the wall.
• Emptying water consists in unscrewing the valve placed at the bottom of the filter. It is equipped with a metal tank cover.
• The device body is made of aluminum so that can withstand up to 16 bar
