Guillotine cutter for electrohydraulic rods 4-16 mm 300 bar 1200 w

€214.90
Tax included
Obecnie brak na stanie
Payment
discover visa googlewallet paypal mastercard americanexpress
  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

Manufacturer's code: 10062741
Guillotine for brand rods MSW It offers an impressive cutting strength and reinforcement steel to 16 mm in diameter in just 3 seconds, even with stretching strength of 650 N / mm². Electrohydraulic scissors for 1200w reinforcing bars and 300 bar working pressures guarantee precise and clean cutting edges. The combination of power, precision and performance means that this is an irreplaceable tool for the production of reinforcements and more. The model can be used to strengthen foundations, beams or columns, as well as for infrastructure projects, such as construction of bridges, tunnels or roads. The ergonomic cutter is very convenient to use. It is also compact, which facilitates transport to the workplace. Electric scissors are equipped with a quick-replacement system. In combination with a solid construction tool for many years. Thanks to the hardness of HRC blades 55 double insulation according to the IEC II protection class and the Class of insulation F (up to 155DEG C), the guillotine provides high reliability and durability even in demanding operating conditions.
Product features:
  • - guillotine for bars cuts reinforcement steel with a thickness of up to 16 mm and maximum tensile strength 650 N / m² in just 3 seconds,
  • - electrohydraulic scissors for reinforcing bars generate a working pressure of 300 bars and 1200 W power, providing clean edges,
  • - the cutter holder for rods is convenient to hold and use, and the compact design facilitates transport to the place of use,
  • - guillotine for cutting rods has a quick-replacement system and is intended for continuous operation according to the nominal operating mode S1,
  • - Rod's shears are distinguished by HRC 55 hardness and double insulation (IEC II protection class) and class F (up to max. 155DEG C).

Technical parameters:
  • - catalog number - 10062741
  • - article - New
  • - Model - MSW-Cutter-b8
  • - frequency [Hz] - 50
  • - Material - Nylon, cast iron, alloy steel
  • - Color - Gray
  • - Tension [V] - 230
  • - Hardness - Stretching strength: 650 N / mm²
  • - cutter size [mm] - 16
  • - cutting time [s] - 3
  • - power [W] - 1200
  • - head dimensions [cm] - 12
  • - pressure [bar] - 300
  • - Cutting range [mm] - 4 - 16 mm
  • - hardness of the blade [HRC] - HRC 55
  • - Insulation class - F
  • - IEC protective class - II
  • - Device work cycle - S1 (continuous work)
  • - Power cord - 1.7 m
  • - Dimensions (DXSXW) - 47 x 23 x 14 cm
  • - weight - 8.2 kg
  • - Dimensions of shipment (DXSXW) - 55 x 18 x 27 cm
  • - shipping weight - 13.3 kg

Included:
  • - guillotine for bars
  • - 4 screws
  • - key
  • - Allen key
  • - oil tank
  • - storage box
MSW
1026458

Data sheet

Kod producenta
1026458
