Andromeda Computers Phoenix X Controller - Thermostat and programmer

Phoenix X Controller:
- Heating (thermostat)
- Cooling (thermostat)
- day / night (separate settings for a time of day)
- programmer (timer)
- Two channels (thermostat / timer)
- Alarm

Phoenix X Controller - More about Features:
It is equipped with two independent channels, where each of them is programmed separately.

- Thermostat:
One of the channels is chips with a microprocessor thermostat. This means that one of the 230V outputs can adjust the temperature inside the terrarium / aquarium / Gworbox "IE and others. The thermostat can raise the temperature or lower it using the appropriate devices. You can set a different temperature per day and for the night.

- Programmer:
Enables and disables connected devices with a given, programmed user with an accuracy of up to 1 minute, time.

- Alarm:
In the event that your external devices (heating cable, heating bulb, etc.) will not be able to warm the terrarium (eg: as a result of burning bulbs) Phoenix x alerts you about this fact. The interrupted beep will turn on. You set the alarm threshold yourself, i.e. when the mechanism is to turn on.

Construction Phoenix X Controller:

- Probe:
The probe with small dimensions is responsible for measuring temperature. This sensor is placed on a wire with a large length - 150cm.

- LCD display:
The external placement of the display significantly facilitates service and cares for aesthetics. Place the display for example: on the terrarium (assembly tapes included) to have easy access. 230V sockets place under the cabinet. They do not have to be visible.

- SCHALL SYSTEM - Microprocessors Andromeda Computers:
Action and programming The accessory is handled by high-class electronic components, including processors and integrated circuits produced by Andromeda Computers. This system guarantees reliability, precision of action, stability and programming comfort.

Andromeda Computers Where did they come from?
The manufacturer of electronic components purchased the possibility of performing thermostats / hygrostaters / and electronic programmers. "They put on their proven technology" inside. In this way, new devices appeared on the market, not only zoological.

Sample device configuration:

- Connect the heating device for the first channel (lamp, mat, cable) and set the time interval, e.g. 10: 00-18: 00. We set the temperature for this interval, e.g. 38ºC. We set the second time interval for 19: 00-9: 00 and temperature on 22ºC.

- Connect the UVB lamp to the second channel and set the time interval for 9: 00-19: 00.

- The device is ready for work. At 8 am, "the sun will seem" ie the UVB bulbs. After an hour, when the sun is higher, the temperature in the terrarium will start to grow up to 38 degrees. Before the evening before the sun falls, the temperature falls, after an hour the sun takes place - a go out UVB lamp. The thermostat maintains the temperature 22 degrees all night until the next day.


Technical data:
- Temperature range from 0 to 50ºC
- Temperature resolution: 0.1ºC
- Accuracy: +/- 1ºC
- Timer: 0-24 H
- Power consumption: 3 W
- Maximum power of connected devices: 1200 W
- Cable length with a probe: 150cm
- probe dimensions: 3.5 x 8mm
- length of the power cable: 100cm
- Cable length between sockets and display: 100cm
