Inverter Inverter Solar MPPT Off-Grid for LCD photovoltaics 5000 W

Manufacturer's code: 10062613

Solar inverter off-grid brand MSW It allows you to design your own power supply regardless of the power grid. Reliably and effectively turns the current from the photovoltaic installation to alternating current for all electrical devices 230 V In the apartment, workshop, office or holiday apartment. You can also store the generated energy in the battery and use it later. Performance 88% It allows full use of the photovoltaic system. Due to DC input voltage of 48 V and AC 230 V output voltage and 50/60 Hz, the device impresses with rated power 5000 W. Therefore, it allows you to power multiple electrical devices, from the refrigerator to drilling machine. MPPT function It fully uses the possibilities of a photovoltaic system and effectively processes electrical energy. All values are displayed on a readable LCD display or through Apply on your smartphone. The solar inverter is not only strong, but also safe thanks to the extensive safety functions against overcharging, excessive discharge, short circuit, overload and overheating. The inverter also impresses a wide range Input voltage from 120 to 430 V. If you want to use electricity later, use the inverter as a charger for eight different types of batteries (not included). A three-stage intelligent charging system will show the best properties at a maximum charging current of 80 A, which is set in the range of 0 - 100% depending on the needs. Additionally, it will prolong the battery life and will provide maximum energy production. If the photovoltaic installation generates more electricity during rush hour or its wear will increase, the solar inverter will support three times the rated power. In the case of generating or wearing a smaller amount, the energy saving mode ensures effective work with low losses.

Product features:

• - Zasil electrical appliances at home, workshop or office using a solar inverter, which will convert current from a photovoltaic installation on the alternating current 230 V,
• - Solar inverter with MPPT technology will receive maximum performance from each panel and improves the effectiveness of the photovoltaic system,
• - thanks to the intelligent, three-point load management system, the solar inverter controls the charging process with the maximum charging current of 80 A,
• - solar-saving energy saving mode allows you to reduce the loss of energy generated, thanks to which it will be used maximally,
• - the inverter stands out with extensive functions protecting against reloading, excessive discharge, short circuit, overload and overheating,
• - All values can be checked on a readable LCD display or using a smartphone application.

Technical parameters:

• - catalog number - 10062613
• - article - New
• - Model - S-Power MPPT 5000
• - frequency [Hz] - 50/60
• - Material - Coated steel
• - Color - White
• - Display - LCD
• - Tension [V] - 230
• - power [W] - 5000
• - efficiency [%] - 88
• - Rated output current [A] - 80
• - Security - Before reloading, excessive discharge, short circuit, overload and overheating
• - voltage range [V] - 120 - 430
• - Maximum solar panel power [W] - 5000
• - Maximum charging current [A] - 80
• - Maximum tension of the open parent circuit of the solar panel [V] - 430
• - Battery voltage - 48 V
• - Dimensions (DXSXW) - 30 x 45 x 11 cm
• - weight - 8.5 kg
• - Dimensions of shipment (DXSXW) - 58 x 41.5 x 13.5 cm
• - shipping weight - 9.9 kg

Included:

• - Solar inverter
