Channel fan exhaust outlet Wed. 315 mm 2000 m3 / h

Manufacturer's code: 10062642
Channel fan brand MSW With axial air flow, large rooms such as production halls or channels are ideal for ventilation. But also quickly and reliably will deliver fresh air to sanitary rooms, offices, bars, warehouses and workshops. The exhaust fan can also be effectively heated and cooled. The housing was designed to ensure a more compressed air flow. This means that The fan will reach yield at 2000 m³ / h. Such efficiency guarantees rapid ventilation of large rooms or widely branched channel systems. The fan is powered by 230 V. It is able to achieve impressive 2480 rpm with 280 W. In addition to efficient parameters, the model made of galvanized steel will also delight with high-quality components that guarantee exceptional strength and longevity. The device is fixed using an integrated handle directly at the place of use, where it will work reliably even in difficult conditions. Thanks to the compact dimensions and outlets with a diameter of 315 mm, the channel fan can easily be installed in many places. The action of the model is very discrete because it works very quiet.
Product features:

• - a channel fan with axial air flow reaches static pressure to 696 PA and will be ideal for ventilation systems,
• - axial fan can be used for ventilation, heating or cooling bars, sanitary rooms, offices, industrial facilities and workshops,
• - the construction made of galvanized steel is extremely strong, thanks to which the industrial fan is suitable for intensive use,
• - the exhaust fan reaches the air flow to 2000 m³ / h, which is why it will look great in large buildings,
• - Thanks to the low noise noise, the environmentally friendly channel fan.

Technical parameters:

• - catalog number - 10062642
• - article - New
• - Model - MSW-Cdair-200s
• - Material - Galvanized steel
• - Color - Silver metallic
• - Tension [V] - 230
• - current [A] - 1.23
• - Air flow [m³/h] - 2000
• - Nominal speed [obr./min] - 2480
• - power [W] - 280
• - Maximum pressure - 696 PA
• - Departure diameter - 315 mm
• - noise level - 68 dB
• - Dimensions (DXSXW) - 44.5 x 43 x 24 cm
• - weight - 7.24 kg
• - Dimensions of shipment (DXSXW) - 45 x 45 x 30 cm
• - shipping weight - 8.48 kg

Included:

• - channel fan
• - Mounting screws
