Manufacturer's code:
10062050Brand deep pump MSW Allows you to pump water from narrow and deep wells, shafts, tanks or tank. The device works on the depth
up to 72 m. An efficient 100W power engine allows you to work with a pump speed
0-2850 rpm and maximum flow rate
6000 L / H. The engine is hermetically sealed and protected against pressure and water. A deep-sea pump is suitable for clean water at temperatures
up to 35Deg C. Housing
stainless steel It is resistant to corrosion and dirt. Wire
50 m It allows you to work the device even at a greater distance.
Distribution box Allows easy pump handling.
Correction switch It protects it against damage.
Product features: - - Reliable operation thanks to the distribution box,
- - strong engine 100W,
- - quick pumping from 6000 l / h,
- - maximum pumping depth 72 m,
- - stainless steel housing resistant to corrosion and dirt.
Technical parameters: - - catalog number - 10062050
- - article - New
- - Model - MSW-Spp44-075-50
- - Tension [V] - 230
- - Material - Stainless steel
- - Maximum lifting height [m] - 72
- - power [W] - 100
- - Maximum waterflow [m³/h] - 6
- - water flow [l/h] - 6000
- - Power cord [m] - 50
- - Diameter of the mounting hole [mm] - 95
- - Operating mode - S1
- - rated current [A] - 5
- - Rated power [W] - 750
- - housing material - Stainless steel
- - Insulation class - Breakfast
- - Maximum water temperature [deg C] - 35
- - rotational speed [obr./min] - 0-2850
- - IP protection degree - Ip68
- - IEC protective class - And
- - Maximum sand content in water [%] - 0,25
- - Maximum number of starts per hour [h] - 50
- - water connection diameter - 1,25
- - Number of degrees (pump rotors) - 10
- - Dimensions (DXSXW) [cm] - 86 x 9.5 x 9.5
- - weight [kg] - 17,2
- - Dimensions of shipment (DXSXW) [cm] - 122.5 x 28 x 12.5
- - shipping weight [kg] - 19,7
Included: - - Submersible pump
- - User manual
