Mill Bijackic Grinder for SawCin Pellet 120 kg / h 2.2 kW

Manufacturer's code: 10280324
Mill of the Wiesenfield brand It allows you to prepare a raw material such as cereal, straw, lucerna or wood chips for the press for pellet production. The efficient machine crush a wide range of grain sizes that can be processed easily. In this way, a fine shot is obtained, which is needed for the production of animal feed or for the production of wood pellets. With the output power 2.2 kW motor Rotating speed 2986 rpm powered by 12 hammers In the mill. With the first-class performance values, you can achieve using a fleet mill. Production volume 60 - 120 kg / h. The amount depends on the type of grain or raw material and moisture content in the material. To get the best results, humidity should not exceed 15%. Grains are strangled to the external sieve by centrifugal forces acting on the mill during grinding. The size of the SITA opening determines how thick they will have a grinder. For the bioaval mill, openings with sizes are available 3, 4 and 7 mm. Ready milling is discharged through a side elapse. The shredder impresses the ease of use, a large tank and a solid construction. This allows you to produce and process large amounts of ground material. A stable work table guarantees safe work.
Product features:

• - Effectively crumbling cereals, straw, wood shavings, alfalfin and the like-similar raw materials for pellet production,
• - 2.2 kW engine reaches a speed of 2986 rpm,
• - depending on the raw material and humidity MIELE 60 - 120 kg / h,
• - various grain sizes thanks to the size of 355 x 160 mm and the size of 3, 4, 7 mm,
• - Stable work table and controlled.

Technical parameters:

• - catalog number - 10280324
• - article - New
• - Model - -Knows pm-400
• - frequency [Hz] - 50
• - Material - Carbon steel, iron
• - Color - Black
• - Production [kg/h] - 60 - 120
• - Sieve dimensions [mm] - 355 x 160
• - SIT hole diameters [mm] - 3, 4, 7
• - Angle adjustment [deg ] - 180
• - FAZ range - 3 phases: 380 V
• - Mesh hole diameter [mm] - 1.5 - 10
• - Permissible humidity of the measured surface [%] - 8 - 15
• - Maximum power - 2.2 kW
• - Number of rolling hammers - 12 PC
• - engine speed [obr./min] - 2986
• - Dimensions (DXSXW) - 59 x 55 x 90 cm
• - weight - 58 kg
• - Dimensions of shipment (DXSXW) - 61 x 49 x 58 cm
• - shipping weight - 68 kg

Included:

• - Bending mill
• - Metal rod
• - Soft plastic hose
• - tank
• - filling pipe
• - A set of screws and nuts
• - 2 metal inlet guides
• - 3 SITA (3/4/7 mm opening size)
