Manufacturer's code:
10021178Laboratory power supply Stamos Soldering Allows you to process the current to constant current. It will work in production, industrial, websites and laboratories and research institutes. The device has
one channelwhich enables precise voltage adjustment in the range
0-60 V and starting current
0-5 a Use knobs. The power of the device is
300 W. Display
Led It allows you to conveniently read the current and voltage values. The power supply is equipped with mode
Stabilization of the output current (CC) and
tension stabilization (CVS). Has
thermal protection (OTP) and
overload (OPP). The fan provides the correct temperature inside. Rubber legs prevent slipping and do not draw surfaces.
Product features: - - 300 W power,
- - adjustment in the range 0-60 V and 0-5 A,
- - knobs for adjusting voltage and intensity,
- - parameters visible on the LED display,
- - OTP and OPP protection.
Technical parameters: - - catalog number - 10021178
- - article - New
- - Model - SEC-ĺş-87
- - connector [mm] - Output sockets, mains power socket, earthing terminal
- - Cooling - Fan, Temperature control
- - Color - Black
- - fuse [A] - 5
- - voltage stabilization coefficient - CV≤20 MV, CC≤20 MA
- - Current stabilization coefficient - CV≤50 MV, CC≤20 MA
- - type - Pulse
- - starting current [A] - 0 - 5
- - Security - OTP, OPP
- - Power cord [m] - 1,1
- - Output voltage [V] - 0 - 60
- - Display - Led
- - Tension [V] - 230
- - power [W] - 300
- - Rated entrance current [A] - 5
- - Rainting - 30 MV, 20 mA
- - Dimensions (DXSXW) - 21.7 x 7.1 x 16 cm
- - weight - 1.5 kg
- - Dimensions of shipment (DXSXW) - 30.3 x 10.8 x 20 cm
- - shipping weight - 1.78 kg
Included: - - Laboratory power supply
- - Connection cable
- - Power cord
- - User manual
